| Technical Data | |
| Details | |
| Dimensions (L×W×H) | 1330 × 410 × 430mm |
| Carton Dimensions (L×W×H) | 1430 × 440 × 460mm |
| Equipment Net Weight | 27.6kg |
| Gross Weight (with carton) | 42.6kg |
| Allowable Operating Temperature | Within 60°C |
| Storage Temperature | 0-50°C |
| Wire Products | Hand ropes, metal wires, heating wires, etc. |
| Electrical Parameters | |
| Working Voltage | 220V-60HZ |
| Rated Voltage | 100V-220V |
| Maximum Output Power | 300W |
| Winding Machine Hardware Parameters | |
| Rotation Speed | 5-1000r/min |
| Maximum Winding Width | 800mm (customizable) |
| Maximum Fixture Diameter | 50mm |
| Tension Adjustment Device | |
| Tension Control Mode | Mechanical adjustable tension |
| Electronic Winding Unit | |
| Winding Distance | 800mm |
| Minimum Wire Diameter Supported | 0.025mm (min) |
| Maximum Wire Diameter Supported | 2mm (max) |
